ADATA LEGEND 860 1000GB Internal SSD

• Brand: ADATA.
• Model: LEGEND 860.
• Product Type: Internal SSD.
• Capacity: 1000GB.
• Transmission Interface: PCIe Gen4 x4 M.2 2280 SSD.
• Read Speed: Up to 6,000MB/s sequential.
• Supports: latest Intel and AMD platforms.
• This drive provides excellent output for: Mid-to-high-end productions such as film and television animation, machine learning, and product modeling.
• Color: Black with Gold.

• Interface: PCIe Gen4 x4.
• Form Factor: M.2 2280.
• NAND Flash: 3D NAND.
• Sequential Read (Max): Up to 6,000MB/s (PC/Laptop).
• Terabytes Written (TBW)(Max Capacity): 640TB.
• MTBF: 2,000,000 hours.
• Shock resistance: 1,500G/0.5ms.
• Operating Temperature: 0°C - 70°C.
• Dimensions ( L x W x H ) & Weight:

• • W / Heat sink:

• • • 80 × 22 × 3.13mm / 3.15 × 0.87 × 0.13inch.
    • 9.5g / 0.33oz.

• • W / O Heat sink:

• • • 80 × 22 × 2.15mm / 3.15 × 0.87 × 0.09inch.
    • 6.5g / 0.23oz.

• Important Note: When installing this disc in a PS5, it is always recommended to use the heat sink version to ensure effective heat dissipation during extended gaming sessions, as the PS5 controller requires good cooling for M.2 discs.

Performance and Speed

• Speed: Delivers sequential read/write speeds of up to 6,000MB/s.
• Comparison: 3x faster than standard PCIe Gen3 SSDs and 10x faster than SATA SSDs.
• Compatibility: Utilizes the PCIe 4.0 interface while maintaining full backward compatibility with PCIe 3.0 platforms.

PS5 Compatibility

• Expansion: Designed to function as an expansion drive for the PS5, helping to resolve storage limitations.
• Experience: Fits perfectly into the PS5 drive slot and ensures smooth, lag-free gameplay for AAA titles.
• Note: Per Sony's guidelines, even with speeds exceeding official requirements, actual performance for some games may vary compared to the console's built-in SSD.

Capacity and Durability

• Capacity: Available in a spacious 1,000GB (1TB) configuration.
• SLC Caching & HMB: Uses SLC caching algorithms and Host Memory Buffer technology for enhanced performance.
• Data Integrity: Employs an LDPC (Low-Density Parity Check) error correction mechanism to ensure data accuracy and file security.
• Longevity: Constructed with high-quality components to maximize Total Bytes Written (TBW) and durability.
• Warranty: Backed by a 5-year warranty following rigorous testing.

SSD Toolbox: Management Software

• Firmware Updates: Helps optimize overall performance and stability.
• Monitoring: The Dashboard continuously monitors S.M.A.R.T. data, allowing users to track:

• • SSD health and remaining lifespan.
  • Current operating temperature.
  • Used and available storage capacity.
