QUICK 8686D+ Dual SMD Rework Station - (Hot Air + Soldering Iron)

• Brand: QUICK.
• Model: 8686D+.
• Precise temperature control.
• Automatic sleep mode.
• Encoder steples speed regulation.
• LED Intelligent digital display.
• Password protection.
• Suitable for the desoldering of a variety of packaged components, maintenance and R&D.
• Color: Black.

• Power: 1350W (70W soldering station).
• Operating voltage: 110V/220V.
• Soldering station temperature: 100℃-480℃.
• Air gun temperature: 100℃-500℃.
• Air volume: 50L/min (Max).
• Temperature stability: ±5℃ (soldering station) / ±2℃ (still air, no load).
• Ambient temperature: 0-40℃.
• Potential of welding tip to the ground: <2mV.
• Resistance of welding tip to the ground: <2Ω.
• Product size: 180 × 210 × 131mm.
• Net weight: About 3.3kg.

• Professional 2-in-1 rework station: Combining a soldering iron and hot air gun.
• Magnetic sensor handle: Automatically enters sleep mode when placed on holder; sleep parameters adjustable.
• 3 customizable channels (CH1 / CH2 / CH3): For quick setting recall.
• Pure copper soldering tip: Ensures fast heating, high thermal conductivity, and durability.
• Automatic cooling system: Brushless fan ensures smooth, stable airflow and prolongs heating element life.
• Precise control: Large LCD with encoder knob allows real-time adjustment of temperature and airflow.
• High efficiency: Suitable for SMD repair, circuit board assembly, and smartphone servicing.
• Extra functions: Password protection, auto sleep, constant heat output, and fast thermal recovery via 4-wire metal heating core.

In the Box

• 1 × Desoldering Station
• 1 × Hot air gun handle
• 1 × Soldering iron tip
• 1 × Soldering iron tip handle
• 1 × Soldering iron tip handle holder
• 1 × Power cord
• 1 × Air gun holder
• 3 × Air nozzle
• 1 × Wrench
• 1 × Instruction manual
